What’s Next For China’s AI Development? A Learning-by-Doing Perspective
AIThis post was created with the assistance of artificial intelligence (AI).

📊 Full opportunity report: What’s Next For China’s AI Development? A Learning-by-Doing Perspective on ThorstenMeyerAI.com — validation score, market gap, and execution plan.

TL;DR

China has begun mass-producing domestic lithography machines and demonstrated 7-nanometer chip production, but significant hurdles remain in yield, materials, and expertise. Progress is real but incremental, emphasizing a phase transition rather than a race.

China has started mass-producing domestic immersion DUV lithography machines capable of manufacturing chips at 28-nanometer nodes, with prototypes of advanced EUV machines also emerging, marking significant progress in its semiconductor capabilities.

Multiple credible sources confirm that China is now producing domestic immersion DUV lithography machines for 28-nanometer chips, with some systems reportedly capable of reaching 7- and 5-nanometer nodes through multi-patterning. SMIC has demonstrated 7-nanometer production using older tools, and Huawei aims to produce over a million high-end AI chips this year, indicating a deliberate move up the technology stack backed by state support.

However, the journey from prototype to reliable, large-scale manufacturing remains complex. SMIC’s current yield for 5-nanometer chips is estimated around 20 percent—far below the 90 percent typical in leading fabs using EUV technology. Additionally, China relies heavily on imported high-purity materials, especially photoresist from Japan, and its domestic tools lag behind international leaders by several generations. The installed base of equipment also depends on Western servicing, creating a dependency that limits self-sufficiency.
